The EGO
vertical shaft
power unit
REPLACING THE
COMBUSTION ENGINE
Constructed using premium components, the PU2700 power unit has a comparative performance to petrol and is engineered to make light work of the toughest jobs. It provides a genuine alternative to traditional combustion engines, while ensuring the highest levels of performance and durability.
- Performance comparable to a 200cc petrol engine
- Higher torque than a petrol engine
- More compact than a petrol engine
- PEAKPOWER™ balances the performance of multiple batteries
- Compatible with all EGO handheld batteries
- Can be connected to an EGO backpack battery
- Two speeds - eco and boost
- Power for a whole working day
The technology
-
PEAKPOWER™
An innovative proactive power output management system. Peak PowerTM senses how many batteries are connected to the system, then regulates the output power automatically.
When two fully charged batteries are in use, the power unit will output the maximum power continuously, meaning both batteries will deplete in power at the same rate.
When one full, and one not full battery are paired, the system can detect this and will automatically discharge the full battery on its own until the power matches that of the remaining battery. Once they’re both at the same power level, the system will change the power output to deplete simultaneously.
-
ARC LITHIUM™ BATTERY SYSTEM
Our revolutionary ARC Lithium 56V battery technology delivers the industry's highest energy capacity in a portable handheld battery. With a range of battery sizes available, from 2.5Ah to 12Ah, and up to 28Ah as a backpack battery, choose the power you need to tackle any task.
The innovative design of EGO’s 56V ARC Lithium battery out-performs petrol-powered products. It is simpler, cleaner, quieter, safer for the environment and, with no emissions and less vibration, safer for users too. Impressive run-times and fast charge-times offer the ultimate in flexibility.
PU2700 DIMENSIONS INCLUDING
PLUG IN ADAPTER
Taking up less room than a traditional 4-stroke engine the EGO Power+ System vertical motor will comfortably fit where a traditional combustion motor would normally go.
The PU2700 is compatible with any EGO handheld battery, from 2.5Ah up to the 28Ah backpack battery. Utilising EGO’s proprietary PEAKPOWER™ technology, the PU2700 can use two batteries simultaneously to maximise power output for particularly challenging operations.
This battery power unit also provides the same compatibility with the additional adaptor to allow for backpack battery usage.
| FUNCTION | PU2700 |
|---|---|
| Voltage | 56V |
| Battery Port | Dual Port |
| BAX1500 Backpack Battery Plug-in Port | Optional |
| Motor Type | BLDC |
| Speed Control | Eco/Boost (two modes) |
| Malfunction LED Indicator | YES |
| Cooling System | Air cooled |
| Air Cleaner | Easy replaceable sponge mesh |
| PTO Shaft | Vertical |
| PTO Shaft Rotation (from PTO shaft side) | Counterclockwise |
| Shaft Diameter | 7/8 inch |
| Shaft Length | 2 7/16 inch |
| Net Power Output | 3.24 HP (2.38 kW) @ 2800 RPM, 3.83 HP (2.82 kW) @ 3000 RPM, 4.12 HP (3.03 kW) @ 3200 RPM, 4.72 HP (3.47 kW) @ 3600 RPM |
| Net Torque | 6.79 ft.lb (9.20 Nm) @ 3600 RPM, 6.67 HP (9.04 Nm) @ 3200 RPM, 6.62 HP (8.97 Nm) @ 3000 RPM, 5.98 ft.lb (8.11 Nm) @ 2800 RPM |
| Start Type | Electronic ON/OFF button |
| Clutch Control | Remote (steel wire) |
| Electronic Brake | YES |
| Assembly Bolt Circle | 8 inch (may require adaptor for mounting hole variations) |
| Length | 15 3/4 Inch |
| Width | 12 1/4 Inch |
| Height | 10 7/8 Inch(w/o shaft) |
| Dry Weight (w/o batteries) | 26 lbs |
| Gross Weight (w/ two 56V10Ah batteries) | 48 lbs |
| IP Class | IPX5 |
The PU2700 opens up a world of opportunity for tools which have been, until now, unable to step into the growing market of battery powered outdoor power equipment.
Thanks to its high performance, the EGO Power Unit offers the possibility of replacing conventional petrol units up to 200cc with a modern, emission free, high-torque, electric powertrain equivalent.
Taking up less room than a traditional 4-stroke engine, the EGO power+ system vertical motor will comfortably fit where a traditional combustion motor would normally go.
The PU2700 is compatible with any EGO handheld batteries from 2.5Ah up to the very latest 12.Ah.
Utilising EGO’s proprietary PEAKPOWER™ technology, the PU2700 can use two batteries simultaneously to maximise power output for particularly challenging operations. It provides the same compatibility with the additional adaptor to allow for backpack battery usage.
